Aquavar ii controller owner’s information record – Xylem IM131R01 AQUAVAR AV II User Manual
Page 3
2
AQUAVAR II Controller Model _________________
Transducer Model_______________________
AQUAVAR II Serial Number
_________________
Transducer Rating_______________________
Date purchased
_________________
Purchased from
_________________
Pump Model
_________________
Software Version _______________________
Pump Code Number
_________________
Program Record
Please use the following to record the final values programmed into the AQUAVAR controller after installa-
tion.
Required Value____________________ (select)
Level 2____________________________ (%)
Autostart ________________________ (on/off)
Intensity 1 _________________________ (%)
Password ________________________ (value)
Intensity 2 _________________________ (%)
Window ___________________________ (%)
Pressure Increase ___________________ (PSI)
Ramp Hysteresis _____________________ (%)
Pressure Decrease___________________ (PSI)
Ramp 1 _______________________ (seconds)
Enable Sequence Control______________ (Hz)
Ramp 2 _______________________ (seconds)
Switch Interval ___________________ (hours)
Ramp 3 _______________________ (seconds)
Optional Value _________________________
Ramp 4 _______________________ (seconds)
Synchron Limit _____________________ (Hz)
Max. Frequency _____________________ (Hz)
Sychron Window ____________________ (Hz)
Min. Frequency ______________________ (Hz)
Pump Address _________________ (# or off)
Config. F Min. __________ (F –>0/F –>F min.)
ADC Reference ___________________ (select)
Stop - Delay F Min._______________ (seconds)
Freq. Lifting________________________ (Hz)
Sensor Adjust _______________ (out of range)
Lift Intensity________________________ (%)
Sensor Curve _____________ (linear/quadratic)
Analog out ______________________ (select)
Sensor Range - 20mA=362.6 __________ (PSI)
Pressure Unit ____________________ (select)
Mode___________________________ (select)
Test Run After__________________ (in hours)
(actuator/controller/multicontroller/synch.)
Test Frequency______________________ (Hz)
Regulation Mode _________________ (normal)
Conveyor Limit _____________________ (PSI)
Start Value _________________________ (PSI)
Delay Time ____________________ (seconds)
Config. Second Value _________________ (off)
Error Reset ______________________ (on/off)
Relay Config.__________________ (run motor)
Display Contrast_____________________ (%)
Offset Input ____________________________
Lock Function ____________________ (on/off)
Level 1 ____________________________ (%)
AQUAVAR II Controller Owner’s Information Record
