ZXLD1366

Document number: DS31992 Rev. 8 - 2

29 of 30

www.diodes.com

October 2013

© Diodes Incorporated

A Product Line of

Diodes Incorporated

ZXLD1366

Suggested Pad Layout

1) TSOT25

2) U-DFN3030-6

3) SO-8EP

Dimensions Value (in mm)

C

0.950

X

0.700

Y

1.000

Y1

3.199

Dimensions Value (in mm)

C

0.950

X

0.500

X1

2.400

X2

2.550

Y

0.600

Y1

1.780

Y2

3.300

Dimensions Value (in mm)

C

1.270

X

0.802

X1

3.502

X2

4.612

Y

1.505

Y1

2.613

Y2

6.500

Y1

C

C

X (5x)

Y (5x)

C

Y1

X1

X

Y

Y2

X2

X2

Y1

Y

C

Y2

X1

X

C-0.409
