6
3-3. Shading 27
3-4. Edge Glow 28
3-5. Bright Spots and Emission Points 28
3-6. Fixed-Pattern Noise 29
3-7. Chicken Wire 29
3-8. Battery, Eyecup and Eyeguard Installation 31
3-9. MUNVM Headmount Adjustments 32
3-10. Headmount/Helmet Mount Adapter Installation 33
3-11. Installation of Helmet Mount 34
3-12. Helmet Mount 34
3-13. Reassembly of Helmet Mount 34
3-14. Weapon Mount Usage 35
3-15. Locating the Magnet 36
3-16. Compass Installation 36
3-17. 3X Magnifier Installation 37
3-18. 3X Magnifier Installation with Focus Ring Adapter 37
3-19. Headmount/Helmet Mount Adapter Operation 38
3-20. Tilt and Flip-up Assembly Mechanisms 40
3-21. View Through Installed Compass 42
3-22. Gain Control 43
4-1. Reinstalling the Neck Pad 47
4-2. Threading the Sliding Bar Buckles 47
A-1. Components of End Item 50
HOW TO USE THIS MANUAL
USAGE
You must familiarize yourself with the entire manual before operating the equipment. Before perform-
ing any kind of maintenance on your device, read the section on maintenance in its entirety. Follow all
WARNINGS, CAUTIONS, and NOTES.
MANUAL OVERVIEW
This manual contains sections on Operating and Maintaining the PVS-14 or 6015 Night Vision Monocu-
lar.
The Components of End Item (COEI) and Basic Issue Items (BII) Lists can be found in Appendix A.
TheAdditional Authorization List (AAL) can be found in Appendix B.
The Expendable and Durable Items List can be found in Appendix C.
The Product Warranty Registration Card can be found in Appendix D.
