16
for shoulder and leg strap attachment. A carrying case strap is also provided which can be attached to
the two D-rings on the back of the carrying case.
g. Shipping and Storage Case
The NVMPS is supplied in a shipping and storage case (Figure 2-3).
2.2.3. EqUIPMENT DATA
The following tables provide information pertaining to the operational, electrical, mechanical, optical,
and environmental characteristics for the monocular.
TABLE 2-1. OPERATOR ADJUSTMENT LIMITS
ITEM LIMITS
Diopter Focus +2 to –6 diopters
Objective Focus 25 cm to infinity
TABLE 2-2. ELECTRICAL DATA
ITEM DATA
Power Source Battery (1.5 Vdc max ea.)
Battery Requirements 1 AA Alkaline or 1 AA 1.5 Vdc Lithium L91
TABLE 2-3. MECHANICAL DATA
ITEM CHARACTERISTICS
Shipping and Storage Case Size: Approx.14” X 9.5” X 8” Weight: 2.4 lbs.
Carrying Case Size: Approx. 14” X 8”
Monocular (see Note) Weight: 14 ounce
NOTE:
Weight of the monocular does not include accessories.
TABLE 2-4. OPTICAL DATA
ITEM DATA
Magnification 1.0X (3X with 3X magnifier)
Field-of-View 40° (13° with 3X magnifier)
Diopter Focus +2 to - 6 diopters
Objective Focus 25 cm (9.8”) to infinity
TABLE 2-5. ENVIRONMENTAL DATA
ITEM DATA
Monocular Operating Temperature -51°C to +49°C
Monocular Storage Temperature -51°C to +85°C
Illumination Required Overcast starlight to moonlight
