20
NOTE :
Low battery indicator and IR source “on” indicator are visible in eyepiece lens.
TABLE 3-1. MONOCULAR CONTROLS AND INDICATORS
CONTROLS AND INDICATORS FUNCTIONS
Power Switch
Controls monocular and IR source, ON or OFF.
RESET/OFF
Same as system OFF. Also resets monocular after high light
cut-off.
ON Monocular activated.
IR/PULL
Turn the knob clockwise to momentarily activate the IR source.
Pull and turn the knob clockwise from the ON position to con-
tinuously activate theIR source.
CAUTION :
Do not use excessive force to place the power switch into the momentary IR position.
Low Battery Indicator
When blinking it indicates a low battery condition with less than 30 minutes
of battery life remaining. It is visible through the eyepiece just outside the
intensified field-of-view.
IR Source On Indicator
When blinking it indicates a low battery condition with less than 30minutes
of battery life remaining. It is visible through the eyepiece just outside the
intensified field-of-view.
Gain Control
(PVS-14 only) Adjusts the system gain from a minimum value of approximately 25 to a
maximum value greater than 3,000.
Objective Focus Focuses objective lens. Adjusts for sharpest image of viewed object.
Diopter djustment
Focuses eyepiece lens for use without the need for glasses. Adjust for sharp-
est image of intensifier screen.
Eye Relief Adjustment Adjusts the distance between your eye and the monocular.
Latch
Latch used for separation of monocular from head-mount/helmet mount
adapter.
Battery Polarity Indi-
cators
This feature, molded into the battery housing, shows the proper orientation
of the battery. Some versions have a bubble molded into the top of the bat-
tery house, to show the + for proper orientation.
