ASUS Motherboard installation guide 13
English
1.6 Installing an expansion card
To install an expansion card:
1. Remove the metal slot cover opposite the expansion card slot where you
wish to install an expansion card.
2. Install the expansion card and make sure that it is properly seated on the slot.
3. Screw to secure the card on the slot.
4. Repeat the previous steps to install another expansion card.
• Refer to the card documentation for the card configuration details, and to
the motherboard user guide in case you need to configure any jumpers
after installing the expansion card.
• Refer to the motherboard user guide for the instructions of the expansion
card signal cable connection.
PCI card PCIE x16 card
PCIE x1 card
