GE
Data Sheet
12A Analog SlimLynx TM Open Frame: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.6Vdc to 5.5Vdc output; 12A Output Current
February 19, 2014 ©2014 General Electric Corporation. All rights reserved. Page 4
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Frequency Synchronization All
Synchronization Frequency Range All 760 800 840 kHz
High-Level Input Voltage All V
IH
2 V
Low-Level Input Voltage All V
IL
0.4 V
Input Current, SYNC All I
SYNC
100 nA
Minimum Pulse Width, SYNC All t
SYNC
100 ns
Maximum SYNC rise time All t
SYNC_SH
100 ns
General Specifications
Parameter Device Min Typ Max Unit
Calculated MTBF (I
O
=0.8I
O, max
, T
A
=40°C) Telecordia Issue 2 Method 1
Case 3
All 15,233,204 Hours
Weight ⎯ 1.1(0.04) ⎯ g (oz.)
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See
Feature Descriptions for additional information.
Parameter Device Symbol Min Typ Max Unit
On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
; open collector or equivalent,
Signal referenced to GND)
Device code with suffix “4” – Positive Logic (See Ordering
Information)
Logic High (Module ON)
Input High Current All I IH ⎯ 1 mA
Input High Voltage All V IH 2 ⎯ V
IN,max
V
Logic Low (Module OFF)
Input Low Current All I IL ⎯ ⎯ 1 mA
Input Low Voltage All V IL -0.2 ⎯ 0.6 V
Device Code with no suffix – Negative Logic (See Ordering
Information)
(On/OFF pin is open collector/drain logic input with
external pull-up resistor; signal referenced to GND)
Logic High (Module OFF)
Input High Current All I IH — — 1 mA
Input High Voltage All V IH 2 — V
IN, max
Vdc
Logic Low (Module ON)
Input low Current All I IL — — 50 μA
Input Low Voltage All V IL -0.2 — 0.6 Vdc
