12A Analog SlimLynx TM Open Frame: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.6Vdc to 5.5Vdc output; 12A Output Current
February 19, 2014 ©2014 General Electric Corporation. All rights reserved. Page 3
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Output Voltage Set-point (with 0.1% tolerance for external
resistor used to set output voltage)
All V
O, set
-1.0 +1.0 % V
O, set
Output Voltage (Over all operating input voltage, resistive
load, and temperature conditions until end of life)
All V
O, set
-3.0 ⎯ +3.0 % V
O, set
Adjustment Range (selected by an external resistor)
(Some output voltages may not be possible depending on the
input voltage – see Feature Descriptions Section) All V
O
0.6 5.5 Vdc
Remote Sense Range All 0.5 Vdc
Output Regulation (for V
O
≥ 2.5Vdc)
Line (V
IN
=V
IN, min
to V
IN, max
) All ⎯ +0.4 % V
O, set
Load (I
O
=I
O, min
to I
O, max
) All ⎯ 10 mV
Output Regulation (for V
O
< 2.5Vdc)
Line (V
IN
=V
IN, min
to V
IN, max
) All ⎯ 5 mV
Load (I
O
=I
O, min
to I
O, max
) All ⎯ 10 mV
Temperature (T
ref
=T
A, min
to T
A, max
) All ⎯ 0.4 % V
O, set
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
and I
O
=I
O, min
to I
O, max
Co = 3x47nF // 2x47 μF
ceramic capacitors)
Peak-to-Peak (5Hz to 20MHz bandwidth) All ⎯ 50 100 mV
pk-pk
RMS (5Hz to 20MHz bandwidth) All 20 38 mV
rms
External Capacitance 1
Without the Tunable Loop TM
ESR ≥ 1 mΩ All C
O, max
2x47 ⎯ 2x47 μF
With the Tunable Loop TM
ESR ≥ 0.15 mΩ All C
O, max
2x47 ⎯ 1000 μF
ESR ≥ 10 mΩ All C
O, max
2x47 ⎯ 10000 μF
Output Current (in either sink or source mode) All I
o
0 12 Adc
Output Current Limit Inception (Hiccup Mode)
(current limit does not operate in sink mode)
All I
O, lim
130 % I
o,max
Output Short-Circuit Current All I
O, s/c
1.5 Arms
(V
O
≤250mV) ( Hiccup Mode )
Efficiency V
O,set
= 0.6Vdc η 72 %
V
IN
= 12Vdc, T
A
=25°C V
O, set
= 1.2Vdc η 81 %
I
O
=I
O, max ,
V
O
= V
O,set
V
O,set
= 1.8Vdc η 85 %
V
O,set
= 2.5Vdc η 87.5 %
V
O,set
= 3.3Vdc η 89 %
V
O,set
= 5.0Vdc η 92 %
Switching Frequency All f
sw
⎯ 800 ⎯ kHz
1 External capacitors may require using the new Tunable Loop TM feature to ensure that the module is stable as well as getting the best
transient response. See the Tunable Loop TM section for details.
