12A Analog SlimLynx TM Open Frame: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.6Vdc to 5.5Vdc output; 12A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.gecriticalpower.com
February 19, 2014 ©2014 General Electric Corporation. All rights reserved. Version 1.0
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 9. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
UNVT012A0X3-SRZ 3 – 14.4Vdc 0.6 – 5.5 Vdc 12A Negative Yes 150029054
UNVT012A0X43-SRZ 3 – 14.4Vdc 0.6 – 5.5 Vdc 12A Positive Yes 150036974
-Z refers to RoHS compliant parts
Table 10. Coding Scheme
Package
Identifier
Family Sequencing
Option
Output
current
Output
voltage
On/Off
logic
Remote
Sense Options
ROHS Compliance
U NV T 012A0 X 3 -SR Z
P=Pico
U=Micro
M=Mega
G=Giga
ND=SlimLynx
Digital Open
Frame
NV=SlimLynx
Analog Open
Frame
T=with EZ
Sequence
X=without
sequencing
12A X =
programm
able output
4 =
positive
No entry =
negative
3 = Remote
Sense
S = Surface
Mount
R = Tape &
Reel
Z = ROHS6
