663 / 664E Installation Guide
CC848921016 r02 December 2012
Page 4
Product Description
Overview
Infinity C™ dc to dc power shelves convert and distribute available battery voltage to another dc voltage. This allows a
single bank of batteries to provide battery reserve for equipment operating at a different dc voltage.
Features
• Positive or Negative output
664 – Positive output
663 – Negative output
• DC to DC Converters
• 48V 30A output
• 24V 75A output
• Distribution
• Plug in circuit breakers
Up to 6
5A to 100A
• GMT fuses
Up to 10
0.18A to 15A
• Controller - Galaxy Pulsar Edge
• Ethernet and RS232 or USB
• Windows GUI compatible via GE EasyView software
• Mounting - 19” or 23” rack mount
• NEBS Level 3
Models
Model
Input
Output
Converter
Output per Converter
663
+24V
-48V
NE030DC48A
30A
664
-48V
+24V
NE075DC24A
75A
2
Available at
3
Nominal voltage
4
CC109112471 or SM48N30L
5
CC109142881
