Data Sheet
12A Digital SlimLynx TM Open Frame: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 12A Output Current
February 19, 2014 ©2014 General Electric Corporation. All rights reserved. Page 29
Hex
Code
Command Brief Description
Non-Volatile
Memory Storage
4A IOUT_OC_WARN_LIMIT
Sets the output overcurrent warning level in A
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r
Function Exponent Mantissa
Default Value 1 1 1 1 1 0 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r r r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 0 1 1 1 0 1
YES
5E POWER_GOOD_ON
Sets the output voltage level at which the PGOOD pin is asserted high. Exponent
is fixed at -10.
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 1 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 1 1 0 1 0 1 0
POWER_GOOD_ON LEVELS
LOW HIGH
95% 105%
92% 108%
90% 110%
YES
5F POWER_GOOD_OFF
Sets the output voltage level at which the PGOOD pin is de-asserted low.
Exponent is fixed at -10.
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 1 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 1 0 1 0 0 1 0
POWER_GOOD_OFF LEVELS
LOW HIGH
92% 108%
90% 110%
88% 112%
YES
