GE
Data Sheet
12A Digital SlimLynx TM Open Frame: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 12A Output Current
February 19, 2014 ©2014 General Electric Corporation. All rights reserved. Page 27
Table 6 (continued)
Hex
Code
Command Brief Description
Non-Volatile
Memory Storage
36 VIN_OFF
Sets the value of input voltage at which the module turns off This must be lower
than VIN_OFF. Supported Values are
• 2.5V to 17.5V in increments of 0.5V
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r
Function Exponent Mantissa
Default Value 1 1 1 1 0 0 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 0 0 1 0 1 0
YES
38 IOUT_CAL_GAIN
Returns the value of the gain correction term used to correct the measured
output current
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r/w
Function Exponent Mantissa
Default Value 1 0 0 0 1 0 0 V
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value V: Variable based on factory calibration
YES
39 IOUT_CAL_OFFSET
Returns the value of the offset correction term used to correct the measured
output current
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r/w r r
Function Exponent Mantissa
Default Value 1 1 1 0 0 V 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r r r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 V: Variable based on factory calibration
YES
40 VOUT_OV_FAULT_LIMIT
Sets the voltage level for an output overvoltage fault. Exponent is fixed at -10.
Four fixed percentages of 108%, 110%, 112%and 115% are available
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 1 0 1
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 0 0 0 1 0 1 0
YES
