Data Sheet
12A Digital SlimLynx TM Open Frame: Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 12A Output Current
February 19, 2014 ©2014 General Electric Corporation. All rights reserved. Page 24
STATUS_VOUT : Returns one byte of information relating to
the status of the module’s output voltage related faults.
Bit
Position
Flag
Default
Value
7 VOUT OV Fault 0
6 X 0
5 X 0
4
VOUT UV Fault 0
3 X 0
2 X 0
1 X 0
0 X 0
STATUS_IOUT : Returns one byte of information relating to
the status of the module’s output voltage related faults.
Bit
Position
Flag
Default
Value
7 IOUT OC Fault 0
6 X 0
5 IOUT
OC Warning 0
4 X 0
3 X 0
2 X 0
1 X 0
0 X 0
STATUS_TEMPERATURE : Returns one byte of information
relating to the status of the module’s temperature related
faults.
Bit
Position
Flag
Default
Value
7 OT Fault 0
6 OT Warning 0
5 X 0
4 X 0
3 X 0
2 X 0
1 X 0
0 X 0
STATUS_CML : Returns one byte of information relating to the
status of the module’s communication related faults.
Bit
Position
Flag
Default
Value
7 Invalid/Unsupported Command 0
6 Invalid/Unsupported Command 0
5 Packet Error Check Failed 0
4 X 0
3 X 0
2 X 0
1
Other Communication Fault 0
0 X 0
MFR_VIN_MIN : Returns minimum input voltage as two data
bytes of information in Linear format (upper five bits are
exponent – fixed at -2, and lower 11 bits are mantissa in
two’s complement format – fixed at 12)
MFR_VOUT_MIN : Returns minimum output voltage as two
data bytes of information in Linear format (upper five bits
are exponent – fixed at -10, and lower 11 bits are mantissa
in two’s complement format – fixed at 614)
MFR_SPECIFIC_00 : Returns information related to the type
of module and revision number. Bits [7:2] in the Low Byte
indicate the module type (000001 corresponds to the
UxDT012 series of module), while bits [7:3] indicate the
revision number of the module.
Low Byte
Bit
Position
Flag
Default
Value
7:2 Module Name 000001
1:0 Reserved 10
High Byte
Bit
Position
Flag
Default
Value
7:3 Module Revision Number None
2:0 Reserved 000
