Lineage Power 4
Data Sheet
October 14, 2009
5 Vdc Input; 1.5 Vdc to 3.3 Vdc Output; 20 W
NH020-Series Power SIPs:
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions.
See Feature Descriptions for additional information
.
Parameter Device Symbol Min Typ Max Unit
Remote On/Off Signal Interface
(VI = VI,min to VI, max; open collector pnp or Compatible, Von/off
signal referenced to GND. See Figure 20 and Feature
Descriptions section)
Logic Low (ON/OFF pin open—Module On)
Ion/off = 0.0 µA
Von/off = 0.3 V
Logic High (VON/OFF > 2.8 V)—Module Off
Ion/off = 10 mA
Von/off = 5.5 V
Turn-on Time
(IO = 80% of IO, max; VO within ±1% of steady state; see
Figure 12)
All
All
All
All
All
Von/off
Ion/off
Von/off
Ion/off
—
–0.7
1.5
0.3
50
6.0
10
5.0
V
µA
V
mA
ms
Output Voltage Set-point Adjustment Range NH020M
NH020Y
NH020G
NH020F
Vtrim
Vtrim
Vtrim
Vtrim 100
100
90
84
—
—
—
— 150
120
110
110
%VO,
nom
%VO,
nom
Overtemperature Protection (shutdown) All TQ31 — 125 — °C
