Data Sheet
October 14, 2009
NH020-Series Power SIPs:
5 Vdc Input; 1.5 Vdc to 3.3 Vdc Output; 20 W
Document Name:
PDF Name:DS00-128EPS (Replaces DS00-127EPS)
Applications
n
Distributed Power Architectures
n
Communication Equipment
n
Computer Equipment
Options
n
Tight Tolerance output
n
-40 °C operation
Features
n
Compatible with RoHS EU Directive 200295/EC
n
Compatible in Pb- free or SnPb reflow environment
n
Nonisolated output
n
High efficiency: 86% typical
n
Small size and low profile:
63.5 mm x 5.6 mm x 14 mm
(2.5 in x 0.22 in x 0.55 in)
n
Remote On/Off
n
Output overcurrent protection
n
Output voltage adjustment
n
Overtemperature protection
n
UL* 60950 Recognized, CSA
†
C22.2 No. 60950-00 Certi-
fied, and VDE
‡
0805 (IEC60950, 3rd edition) Licensed
n
Meets FCC classA radiated limits
RoHS Compliant
Description
The NH020-Series Power SIPs are nonisolated dc-dc converters that operate over an input voltage range of 4.5 Vdc to 5.5
Vdc and provide a precisely regulated dc output. The SIPs have a maximum output current rating of 6 A at a typical full-load
efficiency of 86%. Standard features include remote on/off and output voltage adjustment.
* UL is a registered trademark of Underwriters Laboratories, Inc.
† CSA is a registered trademark of Canadian Standards Association.
