Lineage Power 3
Data Sheet
October 14, 2009
5 Vdc Input; 1.5 Vdc to 3.3 Vdc Output; 20 W
NH020-Series Power SIPs:
Electrical Specifications (continued)
General Specifications
Parameter Device Symbol Min Typ Max Unit
Output Voltage Set Point
(VI = 5.0 V; IO = IO, max; TA = 25 °C)
NH020M
NH020M2
NH020Y
NH020Y2
NH020G
NH020F
NH020F2
VO, set
VO, set
VO, set
VO, set
VO, set
VO, set
VO, set 1.46
1.485
1.75
1.782
2.43
3.18
3.27
1.5
1.5
1.8
1.8
2.5
3.3
3.3 1.54
1.515
1.85
1.818
2.57
3.39
3.33
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Output Voltage
(Over all operating input voltage, resistive load, and
temperature conditions until end of life.)
NH020M
NH020M2
NH020Y
NH020Y2
NH020G
NH020F
NH020F2
VO
VO
VO
VO
VO
VO
VO 1.43
1.455
1.716
1.745
2.39
3.16
3.24
—
—
—
—
—
—
— 1.57
1.545
1.883
1.855
2.61
3.44
3.36
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Output Regulation:
Line (VI = 4.5 V to 5.5 V)
Load (IO = 0 to IO, max)
Temperature (TA = 0 °C to 55 °C)
All
M
Y
F, G
All
—
—
—
—
— —
—
—
—
— 0.1
0.4
0.3
0.1
—
0.4
0.6
0.5
0.3
17
%VO
%VO
%VO
%VO
mV
Output Ripple and Noise Voltage
(See Figures 7—9 and 15.):
RMS
Peak-to-peak (5 Hz to 20 MHz)
F, G, M
Y
All
—
—
— —
—
— —
—
— 25
30
100
mVrms
mVrms
mVp-p
External Load Capacitance (electrolytic) All — 0 — 10,000 µF
Output Current
(Forced convection, 1.5 ms –1 (300 lfm))
All IO 0 — 6 A
Output Current-limit Inception
(VO = 90% of VO, set; see Feature Descriptions
section.)
All IO — 350 — %IO, max
Efficiency
(VI = 5.0 V; IO = IO, max; TA = 25 °C; see Figures 3—6
and 16.)
NH020M
NH020Y
NH020G
NH020F
h
h
h
h 70
73
79
84 72
75
82
86 —
—
—
— %
%
%
%
Switching Frequency All — — 500 — kHz
Dynamic Response
( ΔIO/Δt = 1 A/10 µs, VI = 5.0 V, TA = 25 °C;
see Figures 10 and 11.):
Load Change from IO = 0% to 100% of IO, max:
Peak Deviation
Settling Time (VO < 10% peak deviation)
Load Change from IO = 100% to 0% of IO, max:
Peak Deviation
Settling Time (VO < 10% peak deviation)
All
All
All
All
—
—
—
—
—
—
—
—
80
200
80
200
—
—
—
—
mV
µs
mV
µs
Parameter Min Typ Max Unit
Calculated MTBF (IO = 80% of IO, max TA = 25 °C) 1,400,000 Hours
Weight — — 7(0.25) g (oz.)
