Data Sheet
October 5, 2009 Naos TM NXA025 SIP Non-isolated Power Modules:
10 – 14Vdc Input; 0.8Vdc to 5.5Vdc Output; 25A output current
LINEAGE POWER 7
Characteristic Curves (continued)
The following figures provide typical characteristics for the NXA025A0X at 25 o C.
Mo
du
le
#
1
M
od
ul
e #
2
V
O
(V
)
(1
V
/di
v)
V
O
(V
) (1
V
/di
v)
TIME, t (1ms/div)
Figure 13. Synchronized Start-up of Output Voltage
when SEQ/ENA pins are tied together (Module #1 =
1.5Vdc, Module #2 = 3.3Vdc).
M
odul
e #
1
M
od
ule
#2
V
O
(V
)
(1
V
/d
iv)
V O
(V)
(1
V
/d
iv
)
TIME, t (1ms/div)
Figure 14. Synchronized Shut-down of Output Voltage
when SEQ/ENA pins are tied together (Module #1 =
1.5Vdc, Module #2 = 3.3Vdc).
