Data Sheet
October 5, 2009 Naos TM NXA025 SIP Non-isolated Power Modules:
10 – 14Vdc Input; 0.8Vdc to 5.5Vdc Output; 25A output current
LINEAGE POWER 16
Document No: DS05-034 ver 1.53
PDF name: nxa025_sip_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Product codes
Input
Voltage
Output Voltage
Output
Current
Efficiency
3.3V @ 25A
Connector
Type
Comcodes
NXA025A0X 10 – 14 Vdc 0.8Vdc – 5.5Vdc 25 A 93 % SIP 108975095
NXA025A0X-P 10 – 14 Vdc 0.8Vdc – 5.5Vdc 25 A 93 % SIP 108997565
NXA025A0XZ 10 – 14 Vdc 0.8Vdc – 5.5Vdc 25 A 93 % SIP CC109107166
NXA025A0X-PZ 10 – 14 Vdc 0.8Vdc – 5.5Vdc 25 A 93 % SIP CC109106754
NXA025A0X6Z 10 – 14 Vdc 0.8Vdc – 5.5Vdc 25 A 93 % SIP CC109145736
-Z refers to RoHS-compliant versions.
Table 3. Device Options
Option Suffix
Short Pins
3.6 mm ± 0.25 mm
[0.141 ± 0.010 in.]
6
