Data Sheet
November 29, 2010
PIM300X Series; ATCA Board Power Input Modules
-38 to -75Vdc; 300W Input
LINEAGE POWER 5
Electrical Specifications (continued):
Parameter
Output
Voltage
Symbol Min Typ Max Unit
Management Power Output (MGMT_PWR)
Operating Input Voltage 3.3V/5.0V V
I
-36 -48 -75 Vdc
Output Voltage Set-point 3.3V/5.0V V
O, set
-2.0 ― +2.0 % V
O, set
(V
I
= -48Vdc, I
O
=I
O, max
, T
A
=25°C)
Output Voltage 3.3V/5.0V V
O
-3.0 ― +3.0 % V
O, set
(Over all operating input voltage, resistive
Load and temperature conditions
until end of life)
Output Regulation 3.3V/5.0V
Line (V
I
= V I , min to V I , max ) ― 0.05 0.2 %, V
O, set
Load (I
O
=I
O, min
to I
O, max
) ― 0.05 0.2 %, V
O, set
Temperature (T
A
= T
A,
min to T
A, max
) ― ― 1.00 %, V
O, set
Output Ripple and Noise 3.3V/5.0V
Measured across 22 F Tantalum/ceramic capacitor
V I = V I,nom T
A
= 25 o C, Io = Io,max
RMS (5Hz to 20 MHz bandwidth)
― ― 25 mV
rms
Peak-to-peak (5Hz to 20MHz bandwidth) ― ― 75 mV
p-p
External Load Capacitance 3.3V/5.0V C
O,max
0 ― 1000 F
Output Current
3.3V
5.0V I o
I o
0
0 ―
― 2.4
1.6 Adc
Adc
Output Current-Limit Inception
3.3V
5.0V I o,lim
I o,lim
3
2.5
―
― Adc
Adc
Output Short-circuit Current (RMS) 3.3V I o,sc ― 8 ― A
rms
5.0V I o,sc ― 6 ― A
rms
Dynamic Response
(di/dt =0.1A/
μs, V
I
in= V In,nom , T
A
=25°C)
Load change from I
O
= 50% to 75% of I
O, max
,
Peak Deviation
Settling Time (V
O
<10% of peak deviation)
3.3V/5.0V
V
pk
t
s
3
800
5 %, V
O, set
s
Turn-On Delay and Rise Times
(Io = 80% of Io,max, T
A
=25°C) 3.3V/5.0V Tdelay 20 50 msec
Output voltage overshoot
(Io = 80% of Io,max, V
I = 48Vdc T
A
=25°C)
3.3V/5.0V 3%
%, V
O, set
Output Over Voltage Protection
3.3V
5.0V
Vo, limit
3.7
5.6 5.4
7.0
V
General Specifications
Parameter Min Typ Max Unit
Calculated MTBF (P
in
=80% of P
in, max
, T
A
=40°C, Vin=-48Vdc)
(Per Telcordia SR-332 Issue 1:Method 1 Case 3)
1,362,480 Hours
Weight 34 (1.2) g (oz.)
