Data Sheet
November 29, 2010
PIM300X Series; ATCA Board Power Input Modules
-38 to -75Vdc; 300W Input
LINEAGE POWER 19
Ordering Information
Please contact your Lineage Power’s Sales Representative for pricing, availability and optional features.
Table 1. Device Code
Input
Voltage
Power
Rating
Auxiliary
Output
Voltage
Auxiliary
Output
Current
Connector Type
&
Options
Product
codes
Comcodes
-38 to -75 Vdc 300W 3.3Vdc 2.4A Thru Hole/RoHS PIM300FZ CC109113858
-38 to -75 Vdc 300W 5.0Vdc 1.6A Thru Hole/RoHS PIM300AZ CC109122322
-38 to -75 Vdc 300W 3.3Vdc 2.4A Thru Hole/RoHS PIM300F6Z CC109159190
Table 2. Device Options
Option Device Code Suffix
Short pins: 3.68mm ± 0.25mm
(0.145 in. ± 0.010 in.)
6
Short pins: 2.79mm ± 0.25mm
(0.110 in. ± 0.010 in.)
8
Table 3. Related Products
Description Product Code Comcode
PIM Evaluation Board N/A 848755868
300W Bus converter; 36-75Vdc Input,12Vdc / 25A Output QBW025A0B1 CC109102464
300W Bus converter; 36-75Vdc Input,12Vdc / 25A Output
(With Heat Plate & RoHS compliant)
QBW025A0B1-HZ CC109113643
300W Bus converter; 36-75Vdc Input,12Vdc / 25A Output
(With Basic Insulation & RoHS compliant)
QBW025A0B1-BZ TBD
200W Bus converter; 36-75Vdc Input,12Vdc / 18A Output QBW018A0B1 108989356
200W Bus converter; 36-75Vdc Input,12Vdc / 18A Output
(RoHS compliant)
QBW018A0B1Z TBD
200W Bus converter; 36-75Vdc Input,12Vdc / 18A Output
(RoHS compliant; specifically designed for high capacitance loads
e.g. VRMs)
QBW018A0B1-TZ CC109101846
