40A Analog MegaDLynx TM : Non-Isolated DC-DC Power Modules
4.5Vdc –14.4Vdc input; 0.6Vdc to 2.0Vdc output; 40A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
April 24, 2013 ©2013 General Electric Company. All rights reserved. Version 1.05
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 4. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
MVT040A0X3-SRPHZ 4.5 – 14.4Vdc 0.6 – 2.0Vdc 40A Negative Yes CC109159785
MVT040A0X43-SRPHZ 4.5 – 14.4Vdc 0.6 – 2.0Vdc 40A Positive Yes CC109159793
MVT040A0X3-SRPHDZ 4.5 – 14.4Vdc 0.6 – 2.0Vdc 40A Negative Yes CC150022588
-Z refers to RoHS compliant parts
Table 5. Coding Scheme
Package
Identifier
Family
Input voltage
range
Outpu
t
curren
t
Output
voltage
On/Off
logic
Options
ROHS
Complian
ce
M V T 040A0 X 4 -SR -P -H -D Z
P=Pico
U=Micro
M=Mega
G=Giga
D=Dlynx
Digital
V=DLynx
Analog.
T=with
EZ_Sequence
X=without
sequencing
40A X =
programmable
output
4 =
positive
No entry
=
negative
S =
Surface
Mount
R =
Tape &
Reel
Paralleling 2 Extra
Ground
Pins
D = 105°C
operating
ambient,
40G
operating
shock as
per MIL
Std 810F
Z = ROHS6
