Data Sheet
March 7, 2012

NQR010A0X4: Non-Isolated DC-DC Power Modules

4.5 – 14Vdc input; 0.59Vdc to 6Vdc Output; 10A output current

LINEAGE

POWER

Document No: DS009-011 ver. 1.7

PDF name: NQR010A0X_ds.pdf

Ordering Information

Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 4. Device Codes

Device Code

Input

Voltage Range

Output

Voltage

Output

Current

On/Off

Logic

Connector

Type

Comcodes

NQR010A0X4Z

4.5 – 14Vdc

0.59 – 6Vdc

10A

Positive

SIP

CC109153012

NQR010A0X54Z

4.5 – 14Vdc

0.59 – 6Vdc

10A

Positive

SIP

CC109160090

X4 refers to pin length of 3.29mm
X54 refers to pin length of 5.08mm
Z refers to RoHS-compliant versions
