Data Sheet
March 7, 2012 NQR010A0X4: Non-Isolated DC-DC Power Modules
4.5 – 14Vdc input; 0.59Vdc to 6Vdc Output; 10A output current
LINEAGE POWER 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage All V
IN
-0.3 15 Vdc
Continuous
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
4.5 12 14 Vdc
Maximum Input Current All I
IN,max
10 Adc
(V
IN
=4.5V to 14V, I
O
=I
O, max
)
Input No Load Current
(V
IN
= 12Vdc, I
O
= 0, module ON) V
O,set
= 0.6 Vdc I
IN,No load
29 mA
(V
IN
= 12Vdc, I
O
= 0, module ON) V
O,set
= 5.0Vdc I
IN,No load
58 mA
Input Stand-by Current All I
IN,stand-by
1.505 mA
(V
IN
= 12Vdc, module disabled)
Inrush Transient All I 2 t 1 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN
=0 to
14V
,
I
O
= I
Omax
; See Test Configurations)
All 34 mAp-p
Input Ripple Rejection (120Hz) All 58 dB
