Data Sheet
PicoTLynx TM 6A: Non-Isolated DC-DC Power Modules
2.4Vdc –5.5Vdc input; 0.6Vdc to 3.63Vdc output; 6A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
September 11, 2013 ©2013 General Electric Company. All rights reserved. Version 1.11
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 6. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
APXH006A0X-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 6A Negative No CC109113354
APXH006A0X4-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 6A Positive No CC109113362
APTH006A0X-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 6A Negative Yes CC109113370
APTH006A0X4-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 6A Positive Yes CC109113387
APTH006A0X-SR 2.4 – 5.5Vdc 0.6 – 3.63Vdc 6A Negative Yes CC109144993
-Z refers to RoHS-compliant parts
Table 7. Coding Scheme
TLynx
family
Sequencing
feature.
Input voltage
range
Output
current
Output voltage On/Off logic Options ROHS Compliance
AP T H 006A0 X 4 -SR Z
T = with Seq.
X = w/o Seq.
H = 2.4 – 5.5V 6.0A X = programmable
output
4 = positive
No entry =
negative S = Surface Mount
R = Tape&Reel
Z = ROHS6
