Preliminary Data Sheet
August 9, 2005 FLT007A0/FLT007A0-SR Input Filter Modules
75Vdc Input Voltage Maximum, 7A Output Current Maximum
2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage
Continuous All V
IN
0 75 Vdc
Transient (100ms) V
IN, TRANS
0 100 V
Operating Ambient Temperature All T
A
-40 85 °C
Storage Temperature All T
stg
-55 125 °C
I/O to Ground Isolation (100% Factory Tested) All − − 1500 Vdc
Input to GND Insulation 10 - M Ω
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
0 24/48 75 Vdc
Maximum Input-to-Output Current
(V
IN
= 0 to V
iN,max
) All I
max
12 Adc
Resistance per leg All R 20 m Ω
Maximum Average Current
(T
A
= 60 ° C, 2.03 m/s (400lfm) air)
I
max
12 A
Maximum Average Current
(T
A
= 60 ° C, natural convection)
I
max
8 A
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This power module can be used in a wide variety of applications, ranging from simple standalone operation to an
integrated part of sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included,
however, to achieve maximum safety and system protection, always use an input line fuse. The safety agencies
require a fast-acting fuse with a maximum rating of 15 A (see Safety Considerations section). Based on the
information provided in this data sheet on inrush energy and maximum dc input current, the same type of fuse with a
lower rating can be used. Refer to the fuse manufacturer’s data sheet for further information.
