19
For use in interpreting catalog numbers only. Do not use for developing catalog numbers, as not all combinations are available.
Contact your local GE sales office for availability.
Terminal Blocks
GE Line Block Line Terminal Size Color
451 WN 04 G
451 WN = Screw
WF = Spring
WM = Mini Spring
WC = IDC
WI = W/Fuse Plug
WL = Sensor Plug
W/Spring
02 = 2.5
04 = 4
06 = 6
10 = 10
16 = 16
35 = 35
70 = 70 B = Blue
G = Gray
N = Green
Ground Blocks
GE Line Block Line Block Type Terminal Size Color
451 WN SL 04 N
451 WN = Screw
WF = Spring
WM = Mini Spring
WC = IDC
WI = W/Fuse Plug
WL = Sensor Plug
W/Spring
SL = Ground 02 = 2.5
04 = 4
06 = 6
10 = 10
16 = 16
35 = 35
70 = 70 B = Blue
G = Gray
N = Green
Disconnects
GE Line Block Line Block Type Terminal Size Color
451 WN UK 04 G
451 WN = Screw
WF = Spring
WM = Mini Spring
WC = IDC
WI = W/Fuse Plug
WL = Sensor Plug
W/Spring
UK = Disconnect
UT = Bus Bar Disconnect
UF = w/Fuse Holder
US = w/Diode
UB = Disconnect w/Test Bolts 02 = 2.5
04 = 4
06 = 6
10 = 10
16 = 16
35 = 35
70 = 70 B = Blue
G = Gray
N = Green
Miniature Terminal Blocks – Spring Type
GE Line Block Line Block Type Terminal Size Color
451 WM C1 02 G
451 WM = Mini Spring C1 = Standard Direct Mount
C2 = Direct Mount w/Flange
D1 = Duo Modular Direct Mount
D2 = Duo Modular w/Flange
D3 = Duo Modular Rail Mount
D4 = Duo Modular w/o Marking 02 = 2.5 G = Gray
Fuse Blocks
GE Line Block Line Block Type Terminal Size Fuse Size Fuse Indication Color
451 WN FB 04 B 00 G
451 WN = Screw
WF = Spring
WM = Mini Spring
WC = IDC
WI = W/Fuse Plug
WL = Sensor Plug
W/Spring
FB = Fuse Block 02 = 2.5
04 = 4
06 = 6
10 = 10
16 = 16
35 = 35
70 = 70 A = 5 mm Fuses
B = 1/4” Fuses 00 =No Indication
02 = LED 24V
06 = LED 60V
25 = Neon 250V
35 = LED Indication Built In
45 = Fuse Indication Built In B = Blue
G = Gray
N = Green
Branch Blocks – Duo Feed Through
GE Line Block Line Block Type Terminal Size Configuration Color
451 WN TS 04 E22 G
451 WN = Screw
WF = Spring
WM = Mini Spring
WC = IDC
WI = W/Fuse Plug
WL = Sensor Plug
W/Spring
TS = Branch Standard
TG = Branch Ground
TX = Branch Disconnect 02 = 2.5
04 = 4
06 = 6
10 = 10
16 = 16
35 = 35
70 = 70 S12 = Standard 1 in 2 Out
S22 = Standard 2 in 2 Out
E22 = Standard 1 in 1 Out B = Blue
G = Gray
N = Green
Multitier Blocks
GE Line Block Line Block Type Terminal Size Configuration Color
451 WN MD 04 S G
451 WN = Screw
WF = Spring
WM = Mini Spring
WC = IDC
WI = W/Fuse Plug
WL = Sensor Plug
W/Spring
MD = Double
MT = Triple
DG = Double Ground
TG = Triple Ground 02 = 2.5
04 = 4
06 = 6
10 = 10
16 = 16
35 = 35
70 = 70 S = Standard Mount
V = Vertical Mount B = Blue
G = Gray
N = Green
451 SERIES TERMINAL BLOCKS – CATALOG NUMBER STRUCTURES
451 Series Terminal Blocks
