GE
Preliminary Data Sheet
CLP0212 Open Frame Power Supply
90 - 264Vac input; 12Vdc output; 200W Output Power
October 11, 2013 ©2012 General Electric Corporation. All rights reserved. Page 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute stress ratings
only, functional operation of the device is not implied at these or any other conditions in excess of those given in the operations
sections of the data sheet. Exposure to absolute maximum ratings for extended periods can adversely affect the device reliability.
Parameter Device Min Max Unit
Input Voltage - Continuous All 90 264 Vac
Operating Ambient Temperature All -25 70 °C
(see Thermal Considerations section) CLP0212FPEX5Z01A -40‡ 70 °C
CLP0212FPEXZ02A
CLP0212FPEX5Z03A
-40‡ 85* °C
(in sealed enclosure applications with thermally conductive pad to
enclosure, P
O,max
= 65W)
CLP0212FPEX5Z02A -40 55† °C
(in sealed enclosure applications with thermally conductive pad to
enclosure, P
O,max
= 110W)
CLP0212FPEX5Z03A -40 55† °C
Storage Temperature All -40 85 °C
Humidity (non-condensing) All 5 95 %
Altitude All 4000 m
‡ Startup at -40ºC is limited to 80% of maximum load (160W) for all versions, except the CLP0212FPEXZ02A which can start up at full load.
* Unit is capable of operation up to 85ºC ambient for brief periods of time provided humidity is kept below 40%. Sustained
operation at 85ºC when input voltage is above 230VAC and output power loading is at or near the maximum rated value can
degrade reliability of the product.
† Ambient temperature outside the sealed enclosure containing the power supply.
Electrical Specifications
Parameter Device Min Typ Max Unit
Operating Input Voltage All 90 115/230 264 Vac
Input Source Frequency All 47 50/60 63 Hz
Input Current (V
IN
= 90Vac)
All versions except
CLP0212FPEXZ02A
4 A
RMS
CLP0212FPEXZ02A 1.6 A
RMS
Input Power Factor All 0.95
Inrush Transient Current (V
IN
= 264Vac, T
amb
= 25ºC) All 100 A Peak
Leakage Current to earth ground (V
IN
= 264Vac) All 2 mA
Output Voltage Setpoint All 12 Vdc
Output Voltage Tolerance (due to set point, temperature variations,
load and line regulation)
All -2 2 %
Output Voltage Adjustment Range All 11.4 12.6 Vdc
Output Remote Sense Range All 250 mVdc
Output Load Regulation All 1.5 %Vout
Output Line Regulation All 0.5 %Vout
Output Ripple and Noise – measured with 0.1µF ceramic capacitor in
parallel with 10µF tantalum capacitor, at 25°C 1
Peak-to-peak (20MHz Bandwidth)
All 180 mV p-p
Dynamic Load Response – 50% to 75% load transient, 0.1A/µs slew
rate
Output voltage deviation
Settling Time
All
All
5%
500
%
µs
Output Current
All versions except
CLP0212FPEXZ02A
0 16.7 Adc
Output Current CLP0212FPEXZ02A 0 8.34 Adc
Output Current Limit Inception All 115 % I
O,max
1 Output ripple is 300mV p-p maximum at -40°C. To reduce further, additional external capacitance needed.
