DEH40912 Installation Instructions
g
Record Plus ™
Molded Case Circuit Breaker
Accessories
Cable Operating Mechanism
Congratulations and thank you for choosing the
Record Plus™ family of current-limiting circuit
breakers. This UL-listed handle operating
mechanism kits and cables are suitable for use with
the FC and FE circuit breaker series.
Record Plus™ circuit breakers are designed with a
full line of integrated accessories. All units use the
latest in integrated modular circuit breake r
technology for flexibility in application and
maximizing the product’s utilization and
capabilities.
Record Plus™ circuit breakers are listed b y
TION: This product is NOT suitable for use
in equipment not specifically design to accept it.
Contact the equipment manufacturer for possible
equipment modifications.
ATTENTION: Cet appareil nedoit pas etre
employe dans un equipement non specialement
adapte a cet effet. Contactez le constructeur
concernant les possibles modifications a apporter
a l'equipement.
CAU
Warning: DANGER of electrical shock or injury.
Ensure ALL electrical power supplies are OFF
before installing or removing any devices. Do
not remove circuit protective devices until the
power is turned OFF. The breaker, trip unit, or
accessories MUST ONLY be installed and
serviced by QUALIFIED personnel. See NEMA
publication AB4.
Avertissement: Danger contre les risques
d'électrocutions. S'assurer avant TOUTES
manipulations du disjoncteur que les différentes
sources d'alimentation sont en position OFF. Les
disjoncteurs, unités de protection, ou accessoires
doivent être installés par des personnes qualifiées
et habilitées. Ne pas retirer l’appariel de
protection avant que l’alimentation soit coupée.
Lira NEMA publication AB4.
Underwriters Laboratories to the UL489 standard
and the CSA Standard C22.2, No. 5. These circuit
breakers are certified to EN 60947-2.
These accessories are also for use with our MAG-
BREAK® motor circuit protectors, which meet the
same standards and are UL-recognized components
for use in motor applications. They can also be used
with our molded case switches, which are listed per
Underwriters Laboratories to the UL489 standard.
Record Plus™ circuit breakers and their
accessories are designed and manufactured to
exceed our global customers’ high standards for
reliability and quality.
Figure 1a.FCNBM
mounted on
FC circuit breaker
Figure 1b.FENBM
mounted on
FE circuit breaker
Figure 1. Cable operating mechanism mounted on
Record Plus™ circuit breakers.
