GE
Data Sheet
12V Austin SuperLynx TM 16A: Non-Isolated DC-DC Power Modules
10Vdc –14Vdc input; 0.75Vdc to 5.5Vdc output; 16A Output Current
May 7, 2013 ©2013 General Electric Company. All rights reserved. Page 5
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See
Feature Descriptions for additional information.
Parameter Device Symbol Min Typ Max Unit
Remote On/Off Signal interface
(V
IN
=V
IN, min
to V
IN, max
; Open collector npn or equivalent
Compatible, Von/off signal referenced to GND
See feature description section)
Logic High (On/Off Voltage pin open - Module ON)
Von/Off All V IH — — V
IN
V
Ion/Off All I IH — — 10 μA
Logic Low (Von/Off ≤ 0.3V – Module OFF)
Von/Off All V IL — — 0.3 V
Ion/off All I IL — — 1 mA
Turn-On Delay and Rise Times
(I
O
=I
O, max ,
V
IN
= V
IN, nom,
T
A
= 25 o C, )
Case 1: On/Off input is set to Logic Low (Module
ON) and then input power is applied (delay from
instant at which V
IN
=V
IN, min
until Vo=10% of Vo,set)
All Tdelay — 3 — msec
Case 2: Input power is applied for at least one second
and then the On/Off input is set to logic Low (delay from
instant at which Von/Off=0.3V until Vo=10% of Vo, set)
All Tdelay — 3 — msec
Output voltage Rise time (time for Vo to rise from 10%
of V
o,set to 90% of Vo, set)
All Trise — 4 6 msec
Output voltage overshoot – Startup — 1 % V
O, set
I
O
= I
O, max
; V
IN
= 3.0 to 5.5Vdc, T
A
= 25 o C
Remote Sense Range — — 0.5
Overtemperature Protection All T
ref
⎯ 125 ⎯ °C
(See Thermal Consideration section)
Input Undervoltage Lockout
Turn-on Threshold All 8.2 V
Turn-off Threshold All 8.0 V
