12V Austin SuperLynx TM 16A: Non-Isolated DC-DC Power Modules
10Vdc –14Vdc input; 0.75Vdc to 5.5Vdc output; 16A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
May 7, 2013 ©2013 General Electric Company. All rights reserved. Version 1.71
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 3. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
Efficiency
3.3V @ 16A
Connector
Type
Comcodes
AXA016A0X3-SR 10 – 14Vdc 0.75V – 5.5Vdc 16 A 92.0% SMT 108982661
AXA016A0X3-SRZ 10 – 14Vdc 0.75V – 5.5Vdc 16 A 92.0% SMT CC109104840
AXA016A0X3-SR12* 10 – 14Vdc 0.75V – 5.5Vdc 16 A 92.0% SMT 108993424
AXA016A0X3-SR12Z* 10 – 14Vdc 0.75V – 5.5Vdc 16 A 92.0% SMT CC109104485
* -12 code has 100Ω resistor between sense and output pins, internal to the module. Standard code, without –12
suffix, has 10Ω resistor between sense and output pins.
-Z refers to RoHS compliant codes
