GE
Data Sheet
2A PicoTLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14Vdc input; 0.6Vdc to 5.5Vdc output; 2A Output Current
February 26, 2013 ©2013 General Electric Company. All rights reserved. Page 4
General Specifications
Parameter Device Min Typ Max Unit
Calculated MTBF (I
O
=0.8I
O, max
, T
A
=40°C) Telecordia Issue 2 Method 1
Case 3
APXS 26,121,938 Hours
Weight ⎯ 0.9(0.0317) ⎯ g (oz.)
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See
Feature Descriptions for additional information.
Parameter Device Symbol Min Typ Max Unit
On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
; open collector or equivalent,
Signal referenced to GND)
Device Code with no suffix – Negative Logic (See Ordering
Information)
(On/OFF pin is open collector/drain logic input with
external pull-up resistor; signal referenced to GND)
Logic High (Module OFF)
Input High Current All I IH — — 1 mA
Input High Voltage All V IH 3 — V
IN, max
Vdc
Logic Low (Module ON)
Input low Current All I IL — — 10 μA
Input Low Voltage All V IL -0.2 — 0.3 Vdc
Turn-On Delay and Rise Times
(V
IN
=V
IN, nom
, I
O
=I
O, max ,
V
O
to within ±1% of steady state)
Case 1: On/Off input is enabled and then input power is
applied (delay from instant at which V
IN
= V
IN, min
until V o =
10% of V o, set )
All Tdelay — 5 — msec
Case 2: Input power is applied for at least one second and
then the On/Off input is enabled (delay from instant at
which Von/Off is enabled until V o = 10% of V o, set )
All Tdelay — 5.2 — msec
Output voltage Rise time (time for V o to rise from
10% of Vo, set to 90% of Vo, set)
All Trise — 1.4 — msec
Output voltage overshoot (T
A
= 25 o C 3.0 % V
O, set
V
IN
= V
IN, min
to V
IN, max
,I
O
= I
O, min
to I
O, max
)
With or without maximum external capacitance
Over Temperature Protection All T
ref
140 °C
(See Thermal Considerations section)
