Data Sheet
July 27, 2011
EQW006 Series, Eight Brick Power Modules: DC-DC Converter
36 – 75Vdc Input; 12Vdc Output; 6A Output Current
Document No: DS03-119 ver. 1.10
PDF name: EQW006A0B.pdf
World Wide Headquarters
Lineage Power Corporation
601 Shiloh Road, Plano, TX 75074, USA
+1-888-LINEAGE(546-3243)
(Outside U.S.A.: +1-972-244-WATT(9288))
www.lineagepower.com
e-mail: [email protected]
Asia-Pacific Headquarters
Tel: +86.021.54279977*808
Europe, Middle-East and Africa Headquarters
Tel: +49.89.878067-280
India Headquarters
Tel: +91.80.28411633
Lineage Power reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or
application. No rights under any patent accompany the sale of any such product(s) or information.
Lineage Power DC-DC products are protected under various patents. Information on these patents is available at
www.lineagepower.com/patents
.
© 2010 Lineage Power Corporation, (Plano, Texas) All International Rights Reserved.
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Input Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Product codes
Comcodes
48V (36-75Vdc)
12.0 V
6 A
Negative
Through Hole
EQW006A0B1
108986415
48V (36-75Vdc)
12.0 V
6 A
Negative
Through Hole
EQW006A0B1Z
CC109107034
48V (36-75Vdc)
12.0 V
6 A
Negative
Surface Mount
EQW006A0B1-SB
108994851
48V (36-75Vdc)
12.0 V
6 A
Negative
Surface Mount
EQW006A0B1-SZ
108995635
-Z Indicates RoHS Compliant modules
Table 2. Device Options
*Note: Legacy device codes may contain a –B option suffix to indicate 100% factory Hi-Pot tested to the isolation voltage specified
in the Absolute Maximum Ratings table. The 100% Hi-Pot test is now applied to all device codes, with or without the –B option
suffix. Existing comcodes for devices with the –B suffix are still valid; however, no new comcodes for devices containing the –B
suffix will be created.
Option*
Suffix*
Negative remote on/off logic (On/Off pin fitted)
1
Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
6
Short Pins: 2.79 mm ± 0.25 mm (0.110 in ±0.010 in)
8
Surface mount connections
-S
