6 EntelliGuard R Circuit Breaker Retrofill AKD-6 Installation Manual DEH-41548 02/12
Related Publications
Publication Publication Number
Brochure DEA-532
Snapshot DEE-543
Installation Manual AKD8 DEH-41549
Installation Manual AKD6 DEH-41548
Installation Manual AKD5 DEH-41547
Accessory: Door Interlock (Door Interlock Kit) DEH-41529
Accessory Retrofill Doors Assembly DEH-41563
Accessory: Position Switch Plate & Position Switch Assembly & Wiring (Position Switch Kit) DEH-41530
Accessory: Neutral Rogowski CT Disconnect (Neutral Assemblies) DEH-41531
Accessory: Programmer Disconnects DEH-41532
Accessory: Finger Clusters (Cluster Assemblies) DEH-41533
Accessory: Secondary Disconnects DEH-41534
FAQ DEQ-171
Application Guide DET-753
Guideform Spec DET-754
Spare/Renewal Parts Guide DET-755
Service and Support
In addition to the local field sales office and service teams, GE also has a dedicated AfterMarket team to assist
customers with legacy information, selection, ordering, and upgrading.
Estimated Time to Complete Tasks
It takes about 20 minutes to install a feature-for-feature LSI assembly. This includes racking out the old breaker,
racking in the new breaker, and replacing the door. If new options are desired, or if it’s a 4-wire LSIG circuit or
modifications are needed to the cubicle, then additional time is required. Time also does not include wiring the
secondary disconnect on the Retrofill.
Description
Product Specs
Weight (lbs)
Retrofill Breaker Weight Box Weight 10101653P1 Pallet 10101650P1 Wt
Accessories
Wt
Total
Weight
AKD6 213 16 33 2 264
Retrofill Breaker Weight
PB2 Large Frame Box Wt
10101653P1
Pallet 10101513P1 Wt
Accessories
Wt
Total
Weight
AKD6 213 11 24 2 250
