O-10 Control Word Profile

Select the interpretation of the control and status words corresponding to the installed network. Only the selections valid for the network installed in slot A will
be visible in the Keypad display.
For guidelines in selection of GE Drive profile [0] please refer to the Serial communication via RS 485 Interface section.

Option:

Function:

[0] *

Drive Profile

O-13 Configurable Status Word STW

Option:

Function:

This parameter enables configuration of bits 12 – 15 in the status word.

[0]

No function

[1] *

Profile Default

Function corresponds to the profile default selected in par. O-10 Control Word Profile.

[2]

Alarm 68 Only

Only set in case of an Alarm 68.

[3]

Trip excl Alarm 68

Set in case of a trip, except if the trip is executed by an Alarm 68.

[16]

T37 DI status

The bit indicates the status of terminal 37.
“1” indicates T37 is high (normal)
only available in AF-650 GP.

O-14 Configurable Control Word CTW

Option:

Function:

Selection of control word bit 10 if it is active low or active high

[0]

None

[1] *

Profile default

[2]

CTW Valid, active low

O-50 Coasting Select

Option:

Function:

Select control of the coasting function via the terminals (digital input) and/or via the network.

[0]

Digit Input

Activates command via a digital input.

[1]

Bus

Activates command via the serial communication port or network option module.

[2]

Logic AND

Activates command via the network/serial communication port, AND additionally via one of the digital
inputs.

[3] *

Logic OR

Activates command via the network/serial communication port OR via one of the digital inputs.

NB!
This parameter is active only when par. O-01 Control Site is set to [0] Digital and control word.

O-51 Quick Stop Select

Select control of the Quick Stop function via the terminals (digital input) and/or via the network.

Option:

Function:

[0]

Digital Input

[1]

Bus

[2]

Logic AND

[3] *

Logic OR

NB!
This parameter is active only when par. O-01 Control Site is set to [0] Digital and control word.
