4 How to Configure
4.1.1 IP Settings
All IP-related parameters are located in parameter group EN-##:
EN-00 IP Address Assignment
EN-01 IP Address
EN-02 Subnet Mask
EN-03 Default Gateway
EN-04 DHCP Server
EN-05 Lease Expires
EN-06 Name Servers
EN-07 Domain Name
EN-08 Host Name
EN-09 Physical Address
The OPCMBTCP option offers several ways of IP address assignment.
Setting up drive with manual assigned IP address:
Par. Name Value
EN-00 IP Address Assignment [0] MANUAL
EN-01 IP Address 192.168.0.xxx*
EN-02 Subnet Mask 255.255.255.0*
EN-03 Default Gateway optional
*= Class C IP address example. Any valid IP address can be entered.
NB!
A power-cycle is necessary after setting the IP parameters manually.
Setting up drive with automatic (BOOTP/DHCP) assigned IP address:
Par. Name Value
EN-00 IP Address Assignment [1] DHCP/[2] BOOTP
EN-01 IP Address Read only
EN-02 Subnet Mask Read only
EN-03 Default Gateway Read only
By IP address assigned by DHCP/BOOTP server, the assigned IP Address and Subnet Mask can be read out in par. EN-01 and EN-02. In par. EN-04 DHCP Server,
the IP address of the found DHCP or BOOTP server is displayed. For DHCP only: The remaining lease-time can be read-out in par. EN-05 Lease Expires.
Par. EN-09, Physical Address reads out the MAC address of option, which is also printed on the label of the option. If using fixed leases together with DHCP or
BOOTP, the physical MAC address is linked with a fixed IP address.
NB!
If no DHCP or BOOTP reply has been received after 4 attempts (e.g. if the DHCP/BOOTP server has been powered off), the option will fallback to the last good
known IP address.
