Data Sheet
September 10, 2013 Austin MegaLynx TM SMT: Non-Isolated DC-DC Power Modules:
4.5 – 5.5Vdc input; 0.8 to 3.63Vdc Output; 30A output current
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 20/30A output
LINEAGE POWER 5
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Dynamic Load Response
(dI
O
/dt=5A/ μs; V
IN
=12V, V
o
=3.3V ; T
A
=25°C)
Load Change from Io= 50% to 100% of I
O
,max;
No external output capacitors
Peak Deviation All V
pk
⎯ 350 mV
Settling Time (V
O
<10% peak deviation) All t
s
⎯ 25 ⎯ μs
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
; T
A
=25°C)
Load Change from I
O
= 100% to 50%of I
O
,
max
:
No external output capacitors
Peak Deviation All V
pk
⎯ 350 mV
Settling Time (V
O
<10% peak deviation) All t
s
⎯ 25 ⎯ μs
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
; T
A
=25°C)
Load Change from Io= 50% to 100% of Io,max;
2x150 μF polymer capacitor
Peak Deviation All V
pk
⎯ 250 ⎯ mV
Settling Time (V
O
<10% peak deviation) All t
s
⎯ 40 ⎯ μs
(dI
O
/dt=5A/ μs; V
IN
=V
IN
,
nom
; T
A
=25°C)
Load Change from Io= 100% to 50%of I
O,max
:
2x150 μF polymer capacitor
Peak Deviation All V
pk
⎯ 250 ⎯ mV
Settling Time (V
O
<10% peak deviation) All t
s
⎯ 40 ⎯ μs
General Specifications
Parameter Min Typ Max Unit
Calculated MTBF (V
IN
=12V, V
O
=3.3Vdc, I
O
= 0.8I
O, max
,
T
A
=40°C) Per Telecordia Method
3,016,040 Hours
Weight ⎯ 6.2 (0.22) ⎯ g (oz.)
