Data Sheet
September 10, 2013 Austin MegaLynx TM SMT: Non-Isolated DC-DC Power Modules:
4.5 – 5.5Vdc input; 0.8 to 3.63Vdc Output; 30A output current
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 20/30A output
LINEAGE POWER 28
Ordering Information
Table 2. Device Codes
Product codes
Input
Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
ATH030A0X3-SR 4.5 – 5.5Vdc 0.8 – 3.63Vdc 30A Negative SMT 108996625
ATH030A0X3-SRZ 4.5 – 5.5Vdc 0.8 – 3.63Vdc 30A Negative SMT CC109109550
ATH030A0X3-SRH 4.5 – 5.5Vdc 0.8 – 3.63Vdc 30A Negative SMT CC109102340
ATH030A0X3-SRHZ 4.5 – 5.5Vdc 0.8 – 3.63Vdc 30A Negative SMT CC109109567
ATH030A0X3-SRPH 4.5 – 5.5Vdc 0.8 – 3.63Vdc 30A Negative SMT 108996633
ATH030A0X3-SRPHZ 4.5 – 5.5Vdc 0.8 – 3.63Vdc 30A Negative SMT CC109109583
ATS030A0X3-SR 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT 108996591
ATS030A0X3-SRZ 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT CC109109591
ATS030A0X3-SRH 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT 108996600
ATS030A0X3-SRHZ 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT CC109109600
ATS030A0X3-SRPH 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT 108996617
ATS030A0X3-SRPHZ 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT CC109105285
ATS020A0X3-SR 6.0 – 14Vdc 0.8 – 3.63Vdc 20A Negative SMT CC109132544
ATS020A0X3-SRH 6.0 – 14Vdc 0.8 – 3.63Vdc 20A Negative SMT CC109132552
ATS020A0X3-SRPH 6.0 – 14Vdc 0.8 – 3.63Vdc 20A Negative SMT CC109132560
ATS020A0X3-SRZ 6.0 – 14Vdc 0.8 – 3.63Vdc 20A Negative SMT CC109132577
ATS020A0X3-SRHZ 6.0 – 14Vdc 0.8 – 3.63Vdc 20A Negative SMT CC109132585
ATS020A0X3-SRPHZ 6.0 – 14Vdc 0.8 – 3.63Vdc 20A Negative SMT CC109132593
ATS030A0X3-62SRHZ* 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT CC109139457
ATS030A0X3-62SRPHZ* 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT CC109140951
ATS030A0X3-42SRPHZ* 6.0 – 14Vdc 0.8 – 2.75Vdc 30A Negative SMT CC109145471
* Special codes, consult factory before ordering
