COMPACT POWER LINE SHELVES – MODEL J85480S1
Ordering Information
Part Number Description Comcode Usage
Blank Slot Fillers
Central Office White CC848822263 All
Raven Black CC848781534
Graphite CC848825233
Extensions and mounting brackets
CP 19 inch mounting bracket kit (includes two brackets and mounting hardware) CC109145760 L8
1U high extension bracket kit for 23” cabinets (includes two brackets and mounting hardware) CC848844803 All
2U high extension bracket kit for 23” cabinets (includes two brackets and mounting hardware) 848683009 All
Cables / Connectors for J85480S1 Shelves
Ribbon cable for attaching a controller to the power shelf – 10 ft. One end mates into J1
the other end not terminated. 848738245 L1, L4, L6
Inter-shelf connector for daisy-chaining shelves – 9 in between J1 of 2
nd
and J2 of 1
st
shelf 848738253 L1, L4, L6
2 AWG DC output cable set – 10 ft ( 1 RED and 1 BLACK cable) 848748987 All
AC Input cable: High temperature IEC 320 C13 straight over-mold (one end), NEMA5-15P
plug (one end), 14 AWG, 10 ft
CC848776105 L4, L5
AC input cable: IEC 320 C13 plug (one end), other end not terminated , 14 AWG, 14 ft, 847861192 L1, L4, L9
AC input cable: AMP 3-pin Mate-N-Lok, 14 AWG, 3 ft, other end not terminated CC848763301 L6, L7, L8, L9
AC input cable: AMP 3-pin Mate-N-Lok, 14 AWG, 10 ft, other end not terminated CC848793026 L6, L7, L8, L9
Inter-shelf cable for RS-485 specific shelf. CC848786153 L8
Office alarm cable for RS-485 specific shelf CC848786161 L8
DC input cable – 4 ft CC848794908 L14
Shorting jumper for J1 connector ENABLE for single output shelf (see locating picture) AMP 881545-2 L4, L6,
P1 connector ENABLE jumper for split shelf CC848836107 L7, L9, L14
Pulsar Controllers for J85480S1 Shelves Picture
NE843G 1U standalone Controller (Display, DB9 craft port and RJ45 ethernet) CC109139358
CP843A CP Shelf Mounted Controller (Display and RJ45 ethernet) CC109129895
Cables for Pulsar Controllers
NE843G to CP Shelf Cable Kit (Includes 2ft power and communication cable) CC109144820
J4 Output Alarm Cable 50ft – 24ga solid twisted pair CC848817635
J4 Output Alarm Cable 150ft – 24ga solid twisted pair CC848817643
J3 Input Alarm Cable 50ft – 24ga Stranded CC848817651
J3 Input Alarm Cable 150ft – 24ga Stranded CC848817668
