Data Sheet
August 30, 2011
ESTW004A2C Series DC-DC Converter Power Modules
36–75V
dc
Input; 15.0V
dc
/4.2A
dc
Output
Document No: DS11-015 ver. 1.0
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
ESTW004A2C41Z 48V
(36-75V
dc
) 15.0V 4.2A Negative Through
hole CC109170461
ESTW004A2C841Z 48V
(36-75V
dc
) 15.0V 4.2A Negative Through
hole CC109170494
ESTW004A2C41-HZ 48V
(36-75V
dc
) 15.0V 4.2A Negative Through
hole CC109170486
ESTW004A2C41-SZ 48V
(36-75V
dc
) 15.0V 4.2A Negative Surface
mount CC109170478
Table 2. Device Coding Scheme and Options
