COMPACT POWER LINE SHELVES – MODEL J85480S1
Specifications
Parameter Min Max Notes
Input
AC Input Current, per module 15A
20A IEC-320, C13 type
3
IEC-320, C19 type
4
Output
Programmable output set point 42Vdc 58Vdc Via software
Max Output Current 200A 100Amax on each side
Environmental
Operating Temperature Range -40°C to 65°C for UL recognition and 45°C for VDE certification
Operating Relative Humidity 0 - 95% (non-condensing)
Storage Temperature Range -40°C to 85°C
EMC FCC, EN 55022, CISPR22, Level A, conducted and radiated
Immunity FCC and CISPR22 (EN55022) Class A2
Safety/Standards Compliance
Safety Standards UL60950-1, CAN/CSA C22.2 No 60950-1, EN60950-1 (VDE 0805-1)
Certification Marks
5
VDE Licensed, UL Recognized (Canada and U.S.)
Ordering Information
Part Number Description Comcode Usage
Blank Slot Fillers
Central Office White CC848822263 All
Raven Black CC848781534
Graphite CC848825233
Extensions and mounting brackets
CP 19 inch mounting bracket kit (includes two brackets and mounting hardware) CC109145760 L8
1U high extension bracket kit for 23” cabinets (includes two brackets and mounting hardware) CC848844803 All
2U high extension bracket kit for 23” cabinets (includes two brackets and mounting hardware) 848683009 All
Cables for J85480S1 Shelves
Individual wire ser cable for attaching a controller to the power shelf – 6 ft. One end mates
into J1 the other end not terminated. CC848854034 All
Cable set from J1 of the shelf to the CPL Interface Board CC848848960 All
Inter-shelf cable set for interconnecting J2 signals between shelves CC848848952 All
Output cable set: 2 AWG DC Lug termination– 10 ft ( 1 RED and 1 BLACK cable) 848748987 L20, L21, L22, L23
m6 screw with conical washer 901377010 L20, L21, L22, L23
Output cable set: FastON terminations one end – 10ft 3 red and 3 black 10ga wires CC848851931 L24, L25, L29
AC input cable: IEC 320 C13 plug (one end), other end not terminated , 14 AWG, 14 ft, 847861192 L22, L23
AC input cable: IEC320 C19 straight plug (one end), other end not terminated CC848847368 All but L22 & L23
AC input cable: IEC320 C19 right angle plug (one end), other end not terminated 848713376 All but L22 & L23
3
IEC320 – C13 plugs are rated for 10A international and 15A in North America
4
IEC320 – C19 plugs are rated for 16A international and 20A in North America
5
Certifications pending
