EntelliGuard® E Circuit Breaker
DEH-41526
8
©2012 General Electric All Rights Reserved
SECTION 2 – PRODUCT SPECIFICATIONS
WARNING
IMPROPER INSTALLATION, OPERATION AND MAINTENANCE
Ensure only qualified personnel install, operate, service and maintain all electrical equipment.
Failure to comply with these instructions could result in death or serious injury.
TABLE 2.1. ENVIRONMENTAL CONDITIONS
Characteristic Parameter
Temperature:
Ambient for Normal Operation
Ambient at 10% of listed endurance operations inside panel
Storage
-5 ºC to 70 ºC, 40 ºC max without derating
-20 ºC to -5 ºC
-40 ºC to 70 ºC
Humidity
20% RH to 95% RH
Salt fog
per ASTM-B117
Vibration (random and sinusoidal)
1 G max., 50 Hz to 500 Hz in X, Y, Z directions
Fungus resistance
per ASTM G21
Voltage and current de-rating at altitude above sea level
per ANSI C37.20.1, Tables 2 and 3
Noise level
<30 dB
Endurance:
closing coil, Shunt trip
motor operator
20,000 operations
12,500 operations
TABLE 2.2. ENTELLIGUARD E SHORT CIRCUIT AND INTERRUPTING RATINGS: ANSI/UL1066
Interrupting Rating Tier ANSI/UL1066 Devices, LVPCB
Envelope 1
Envelope 2
Type
240 V
480 V
600 V
1/2S Withstand
400,
800,
1200
400, 800,
1600,
2000
3200
400-3200
S 65,000 65,000 50,000
50,000
X
N 65,000 65,000 65,000
65,000
X X
H 85,000 85,000 65,000
85,000
X
P 100,000
100,000 65,000
65,000
X
E 85,000 85,000 85,000
85,000
X
M 100,000 100,000 85,000
85,000
X
TABLE 2.3. AGENCY CERTIFICATION
(All industry standards referenced in this table are the latest version at the time the product is sold.)
Standard Number
Title
ANSI C37.13,16,17, 20, 50
Low-voltage AC Power Circuit Breakers
UL 1066
Low voltage AC and DC Power Circuit Breakers Used in Enclosures
CSA 22.2, No 5.1
Molded-Case Circuit Breakers, Molded-Case Switches and Circuit-Breaker Enclosures
TABLE 2.4. PRODUCT DIMENSIONS AND WEIGHTS
Type
Width Depth Height
Weight
in. mm in. mm in. mm lbs. kg
Envelope
1
13.07 332 16.34 415 17.24 438 149.9 68
Envelope 2, Up to 2000A
17.01
432
16.34
415
17.24
438
176.4
80
Envelope 2, Up to 3200A
17.01
432
16.34
415
17.24
438
209.4
95
