Data Sheet
November 29, 2011
ESTW010A0A Series Eighth-Brick Power Modules
36
–75Vdc Input; 5.0Vdc Output; 10A Output Current
LINEAGE POWER 4
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions for additional information.
Parameter Device Symbol Min Typ Max Unit
Remote On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
; open collector or equivalent,
Signal referenced to V
IN-
terminal)
Negative Logic: device code suffix “1”
Logic Low = module On, Logic High = module Off
Positive Logic: No device code suffix required
Logic Low = module Off, Logic High = module On
Logic Low - Remote On/Off Current All I
on/off
0.15 mA
Logic Low - On/Off Voltage All V
on/off
-0.7 0.6 V
dc
Logic High Voltage – (Typ = Open Collector) All V
on/off
2.4 15 V
dc
Logic High maximum allowable leakage current All I
on/off
25 μA
Turn-On Delay 1 and Rise Times
(I
O
=I
O, max ,
V
IN
=V
IN, nom,
T
A
= 25 o C)
Case 1: Input power is applied for at least 1 second
and then the On/Off input is set from OFF to ON (T
delay
= from instant at which On/Off signal is ON until V
O
=
10% of V
O, set
).
All T
delay
― 20 ― msec
Case 2: On/Off input is set to Logic Low (Module
ON) and then input power is applied (T
delay
from
instant at which V
IN
= V
IN, min
until V
o
=10% of V
O,set
)
All T
delay
― ― 150 msec
Output voltage Rise time (time for V
o
to rise from 10%
of V
o,set
to 90% of V
o, set
)
All T
rise
― 15 ― msec
Output voltage overshoot – Startup
All ― 3 % V
O, set
I
O
= I
O, max
; V
IN
=V
IN, min
to V
IN, max
, T
A
= 25 o C
Prebias Output Load Performance:
All Monotonic
Output Start up characteristic
Back Bias current drawn from output (Module Enabled) All -150 mA
dc
Remote Sense Range All V
SENSE
10 % V
O, set
Output Voltage Adjustment range All 80 110 % V
O, set
Output Overvoltage Protection (Co,min=220 μF) 2 All V
O, limit
6.0 7.0 V
dc
Overtemperature Protection – Hiccup Auto Restart All T
ref
135 O C
Input Undervoltage Lockout All V
UVLO
Turn-on Threshold 32 34.5 V
dc
Turn-off Threshold 27.5 30 V
dc
Hysteresis 1 2 V
dc
1. The module has an adaptable extended Turn-On Delay interval, T
delay
, of 20mS. The extended T
delay
will occur when the module restarts
following either: 1) the rapid cycling of Vin from normal levels to less than the Input Undervoltage Lockout (which causes module
shutdown), and then back to normal; or 2) toggling the on/off signal from on to off and back to on without removing the input voltage. The
normal Turn-On Delay interval, T
delay
, will occur whenever a module restarts with input voltage removed from the module for the preceding 1
second.
2. The module requires a minimum of 220 μF external output capacitor to prevent shutdown during no load to full load transients and to avoid
exceeding the OVP maximum limits during startup into open loop fault conditions.
