Your AF 650 GP Bypass Panel comes with an AF 650 GP Adjustable Frequency Drive from GE Drives mounted
on or in an enclosure which contains the following equipment to manually or automatically allow motor
operation across-the-line in addition to motor operation from the drive.
ABB
/ FERRAZ SHAWMUT Non-Fused Disconnect w/through-the-door lockable handle (or equivalent)
ABB
/ FERRAZ SHAWMUT Fused Disconnect w/through-the-door lockable handle (optional) (or
equivalent)
GE Spectra RMS
TM
Mag-Break Solid State Circuit Breaker w/through-the-door lockable handle
GE C-2000
TM
3-Pole Non-Reversing Contactors
ABB Nema Contactors(Optional)
GE Harmonic Matrix filters – D Series (Optional)
GE C-2000
TM
Class 20/30 Fixed Heater Motor Overload Relays
GE C-2000
TM
Selector Switches with Pilot lights.
GE Type IP Encapsulated or Vacuum Impregnated 115 VAC Control Power Transformer w/fuses
Bussman / Ferraz Shawmut Amp-trap
Time-Delay Class J Fuses (or equivalent)
GE Line Reactors (optional)
GE Load Reactors (optional)
These instructions are intended as a supplement to the User’s Guide for the AF 650 GP drive. For programming,
operating and troubleshooting instructions for the adjustable frequency drive please refer to the User’s Guide,
which is included with your bypass panel documentation package.
DET - 607
AF 650 GP User’s Guide for up to 50HP @ 208V @ & up to 100HP @460/575
DET - 608
AF 650 GP User’s Guide for 125HP and above @ 460/575V
Also included with your bypass panel documentation package are installation instructions, electrical and
mechanical drawings of your bypass panel.
DEH40652
– Page 1
AN 11-2021 Rev 06, 12/16/2011
OPERATING AND TROUBLESHOOTING INSTRUCTIONS FOR
AF 650 GP BYPASS PANELS
