The following information is provided for reference use during the installation of your AF-650 GP Bypass, Non-
Bypass & Disconnect Drive Panels. Please note that all equipment shall be installed in accordance with the
2008 edition of NFPA 70 (National Electric Code) along with applicable local codes. This document provides
information pertaining to: inspections, environment, installation, and wiring. The AF-650 GP Drive User’s Guide
(DET - 607 or DET - 608) and the AF-650 GP Panel Operating Instructions contained in this notebook have
additional information and will be referenced through out this document.
INSPECTION #1
After unpacking your control panel inspect it for damage that may have occurred
during shipment.
If any damage is found please report it to the distributor from which the panel was
purchased.
PREPARING FOR
Remove and discard desiccant / drying / silica packs, if included.
INSTALLATION
Before you begin to install the drive panel, make sure the proper equipment for lifting is
available. Refer to the appropriate Outline drawing for the dimensions, estimated
weight, and required clearances for installation.
Review the Layout and Elementary diagrams before wiring your AF-650 GP panel.
ENVIRONMENT
AF-650 GP NON Bypass and Bypass Panels are available in different NEMA types of
enclosures. These types of enclosures consist of NEMA 1, 12 & 3R. The environment
must also be totally free from flammable or combustible vapors and/or dust.
DEH40650
– Page 1 AN 12-1007 Rev 05, 04/04/2012
CAUTION: Care should be taken when unpacking the panel; improper
use of tools could damage equipment.
WARNING: Improper lifting of enclosure could result in a fatal or
serious injury.
INSTALLATION AND START-UP INSTRUCTIONS FOR
AF-650 GP BYPASS, NON-BYPASS & DISCONNECT DRIVE PANELS
CAUTION: On Wall-Mounted enclosures the panel doors can swing
through 180+ degrees and there are no stops to inhibit the door from hitting
equipment located next to the panel. This could result in damage to the
door mounted switches and indicator lights on the panel door.
WARNING: Failure to comply to this instruction could result in a fire and/or
explosion, thus resulting in a fatal or serious injury.
