ASTAT-SD ™ Solid-State Reduced Voltage Starters
Chapter 1. Technical Specifications
1
1-1 IEC Ratings
450% nominal current for 30 sec. max.
Catalog
Current HP KW
No.
Rating 220/ 380/
440V
480V/ 220/ 380/
440V
480V/
Amps 240V 415V 500V 240V 415V 500V
QS2BNA 5 1.5 3 3 4 1.1 2.2 2.2 3
QS2DNA 9 3 5.5 5.5 7.5 2.2 4 4 5.5
QS2FNA 12 4 7.5 7.5 10 3 5.5 6.3 7.5
QS2GNA 16 5 7.5 10 13.5 3.7 6.3 7.5 10
QS2HNA 22 7.5 13.5 14.5 17.5 5.5 10 12 13
QS2INA 34 10 20 20 25 7.5 15 17 20
QS2INA* 34 10 20 25 25 7.5 15 18.5 20
*300% nominal current for 30 sec. max.
1-2 UL Ratings
450% nominal current for 30 sec. max.
Catalog
Current Max. HP
No.
Rating Starting
200V 230V 460V
Amps Current
QS2BNA 5 25 1 1 3
QS2DNA 9 45 2 2 5
QS2FNA 12 60 3 3 7.5
QS2GNA 16 80 3 5 10
QS2HNA 22 110 5 7.5 15
QS2INA 34 160 7.5 10 20
QS2INA* 34 160 10 10 25
*300% nominal current for 30 sec. max.
