Restore the LAN Connection to Client Mode
As good policy, always leave the controller in Client mode.
Step Action
1.
Press Menu or Accept key,
■
.
2. Press down arrow, ▼, to Configuration.
3.
Press the right arrow key, ► (or square “accept” key,
■
) to advance.
4. Press down arrow, ▼, to Communications Ports.
5.
Press the right arrow key, ► (or square “accept” key,
■
) to advance.
6. Press down arrow, ▼, to Network Settings.
7.
P Press the right arrow key, ► (or square “accept” key,
■
) to advance.
8. Press down arrow, ▼, to highlight DHCP.
9.
Press the right arrow key, ► (or square “accept” key,
■
) to advance.
10. Press down arrow, ▼, to toggle to CLIENT.
11.
Press save,
■
.
12. Press the Back Arrow, §, to return to the default screen.
13. Wait 2 minutes.
14. Activate changes by removing the QS941 controller circuit card from the backplane. Wait until
the LEDs extinguish.
15. Reapply power by reinserting the circuit card connection until seated.
16. Verify Client Mode by pressing Menu>Configuration>Communications Ports>Network
Settings> to show Client mode.
TECHNICAL SUPPORT GUIDE CC84885345
CPS3200U, QS982A, QS941A, Upstream Systems 16
