Data Sheet
August 13, 2013 TLynx TM : Non-isolated DC-DC Power Modules:
2.4 – 5.5Vdc input; 0.6Vdc to 3.63Vdc output; 20A output current
LINEAGE POWER 23
Document No: DS07-014 ver. 1.10
PDF name: APTH020A0X_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 6. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
APTH020A0X3-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 20A Negative SMT CC109130507
APTH020A0X43-SRZ 2.4 – 5.5Vdc 0.6 – 3.63Vdc 20A Positive SMT CC109130515
APTH020A0X3-SR 2.4 – 5.5Vdc 0.6 – 3.63Vdc 20A Negative SMT CC109147492
-Z refers to RoHS-compliant parts
Table 7. Coding Scheme
TLynx
family Sequencing
feature.
Input voltage
range
Output
current
Output voltage On/Off logic Options ROHS
Compliance
AP T H 020A0 X 4 -SR Z
T = with Seq.
X = w/o Seq.
H = 2.4 – 5.5V 20.0A X =
programmable
output
4 = positive
No entry =
negative S = Surface Mount
R = Tape&Reel
Z = ROHS6
