Data Sheet
August 13, 2013 TLynx TM : Non-isolated DC-DC Power Modules:
2.4 – 5.5Vdc input; 0.6Vdc to 3.63Vdc output; 12A output current
LINEAGE POWER 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage All V
IN
-0.3 6 Vdc
Continuous
Sequencing Voltage APTH V
SEQ
-0.3 V
iN, Max
Vdc
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
2.4 ⎯ 5.5 Vdc
Maximum Input Current All I
IN,max
19.5 Adc
(V
IN
=2.4V to 5.5V, I
O
=I
O, max
)
Input No Load Current V
O,set
= 0.6 Vdc I
IN,No load
47 mA
(V
IN
= 5.0Vdc, I
O
= 0, module enabled) V
O,set
= 3.3Vdc I
IN,No load
52 mA
Input Stand-by Current All I
IN,stand-by
5 mA
(V
IN
= 5.0Vdc, module disabled)
Inrush Transient All I 2 t 1 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN
=0 to
5.5V
,
I
O
= I
Omax
; See Test Configurations)
All 12 mAp-p
Input Ripple Rejection (120Hz) All 43 dB
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This power module can be used in a wide variety of applications, ranging from simple standalone operation to an
integrated part of sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included;
however, to achieve maximum safety and system protection, always use an input line fuse. The safety agencies
require a fast-acting fuse with a maximum rating of 20A (see Safety Considerations section). Based on the
information provided in this data sheet on inrush energy and maximum dc input current, the same type of fuse with a
lower rating can be used. Refer to the fuse manufacturer’s data sheet for further information.
