Data Sheet
September 10, 2013 ATL010A0X43-SR Non Isolated Module 12Vdc, Programmable:
9 – 18Vdc input; 0.75Vdc to 5.5Vdc Output; 10A output current
LINEAGE POWER 21
Document No: DS05-008 ver.1.23
PDF name: atl010a0x43-sr_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
Efficiency
3.3V@ 10A
On/Off
Logic
Connector
Type
Comcode
ATL010A0X43-SR 9 – 18Vdc 0.75 – 5.5Vdc 10 A 93.0% Positive SMT 108996154
ATL010A0X43-SRZ 9 – 18Vdc 0.75 – 5.5Vdc 10 A 93.0% Positive SMT CC109107851
-Z refers to RoHS-compliant codes
