Data Sheet
September 10, 2013 ATL010A0X43-SR Non Isolated Module 12Vdc, Programmable:
9 – 18Vdc input; 0.75Vdc to 5.5Vdc Output; 10A output current
LINEAGE POWER 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are
absolute stress ratings only, functional operation of the device is not implied at these or any other conditions in
excess of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for
extended periods can adversely affect the device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage All V
IN
-0.3 18 Vdc
Continuous
Sequencing Voltage All V
SEQ
-0.3 V
iN, Max
Vdc
Operating Ambient Temperature All T
A
-40 85 °C
(see Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage All V
IN
9.0 12.0 18.0 Vdc
Maximum Input Current All I
IN,max
7.0 Adc
(V
IN
= V
IN, min
to V
IN, max
, I
O
=I
O, max
V
O,set
= 5.5Vdc)
Input No Load Current V
O,set
= 0.75 Vdc I
IN,No load
40 mA
(V
IN
= 12.0Vdc, I
O
= 0, module enabled) V
O,set
= 5.0Vdc I
IN,No load
100 mA
Input Stand-by Current All I
IN,stand-by
2.0 mA
(V
IN
= 12.0Vdc, module disabled)
Inrush Transient All I 2 t 0.4 A 2 s
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 1μH source impedance; V
IN, min
to
V
IN, max,
I
O
= I
Omax
; See Test configuration section)
All 20 mAp-p
Input Ripple Rejection (120Hz) All 30 dB
CAUTION: These power modules can be used in a wide variety of applications ranging from simple standalone
operation to an integrated part of sophisticated power architectures. To preserve maximum flexibility, no internal fuse
has been provided. Also, extensive safety testing has shown that no external fuse is required to protect the unit.
However, it is still recommended that some type of current-limiting power source be used to protect the module and
evaluated in the end-use equipment.
